Coordinate power distribution, cooling systems and maintenance access in hyperscale and colocation data centers. Connect the model to installation sequences and phased delivery through an agreed BIM and 4D review workflow.

What we coordinate in a data center

BIM coordination connects power, cooling and maintenance access. 4D review adds installation sequencing and phased delivery for hyperscale and colocation projects, based on each facility’s constraints.

Work packages and deliverables for scoping
PackageInformation to coordinateDeliverable to agree
PowerSwitchgear, UPS, bus duct, cable trays and access routes.Coordinated model, maintenance-clearance review and assigned issues.
CoolingChilled water, CRAC/CRAH equipment, distribution and interfaces with other systems.Coordination views, interfaces and outstanding constraints for team review.
Phasing and commissioningZones, milestones, temporary routes and boundaries between new and operational areas.Model-to-schedule mapping and 4D views of the agreed work packages.

4D coordination and phased delivery

  1. 1. Define zones and milestones

    Agree installation areas, work packages and review points with the scheduling team.

  2. 2. Link the model and schedule

    Map elements to activities and review power, cooling and access dependencies.

  3. 3. Review constraints and update

    Record decisions, owners and revisions before issuing the next sequence.

This illustrative sequence describes reviews and deliverables. Dates, dependencies and commissioning conditions are agreed with the responsible project participants.

Explore 4D scheduling and schedule-linked models
Sector Challenges

Power and Cooling Interfaces

Switchgear, UPS, bus duct, cooling equipment and distribution routes compete for space. Review system interfaces and the project-defined installation and maintenance clearances across overhead and underfloor pathways.

Schedule and Release Constraints

Coordination decisions need to align with procurement, installation and review milestones. Track outstanding constraints, their owners and the information needed before each work package is released.

Modular and Phased Delivery

Increasingly, data centers are built in modules or phases to bring capacity online faster. 4D scheduling and BIM coordination must account for phased commissioning, temporary utility routing, and construction sequencing that doesn't disrupt live capacity.

Our Approach

We review power, cooling and fire-suppression interfaces by zone and work package. The team records clash decisions, access constraints, model revisions and issue owners. Schedule-linked reviews make installation dependencies and phased handovers visible to the responsible project participants.

Deliverables
Data center BIM Execution Plan with agreed zones, model requirements and responsibilities
Power distribution BIM coordination (switchgear, UPS, bus duct, PDU)
Cooling systems coordination (chilled water, CRAC/CRAH, economizers)
Overhead and underfloor pathway management model
Phased 4D model for modular capacity delivery
Coordination of fire-suppression interfaces specified by the project
Frequently Asked Questions

What is unique about BIM coordination for data centers vs. commercial buildings?

Power, cooling and connectivity infrastructure are central to the coordination scope. Review their installation interfaces and defined maintenance clearances together with the zones and milestones for phased capacity delivery.

Can you coordinate both hyperscale and colocation data centers?

Yes. The coordination principles are the same power density, cooling, and schedule are the drivers in both cases. Hyperscale tends to have larger, more standardized row configurations; colocation has more complex multi-tenant separation and power metering requirements. We tailor the BEP to each facility type.

How do you handle schedule compression on data center projects?

We prioritize coordination decisions against the agreed release and installation milestones. Open constraints, issue owners and required source information remain visible, while 4D review helps the team discuss sequencing and access dependencies.

Do you coordinate raised-floor vs. overhead MEP configurations?

Yes to both. Underfloor configurations (raised access floors with cold/hot aisle containment) require coordination of the power and data cabling pathways. Overhead configurations require precise coordination of cable trays, bus duct, and cooling distribution within the overhead plenum.

Can 4D review support phased commissioning?

The model can be linked to installation and handover milestones to review work areas, temporary routes and interfaces with operational capacity. The commissioning team defines the testing requirements, dependencies and acceptance conditions that the sequence must represent.

Core Service

See all projects and details for BIM Coordination

BIM Coordination

Data Centers project?

Tell us about your project we respond within one business day.

Request a Quote

Team experience in data centers

Giankeving Guzman’s profile describes his work as Senior VDC Engineer at Ryan Companies US for a 792 MW data center campus. This is professional experience with that employer, rather than an EZ-VDC contract.
